Intelligent Barrier Gate With Folding Boom and Anti-bumping Functions

Name: Intelligent Barrier Gate With Folding Boom and Antibumping Functions
Brand: WEJOIN
Price: 1 USD

China Intelligent Barrier Gate With Folding Boom and Anti-bumping Functions wholesale

Place of Origin : China

Brand Name : WEJOIN

Certification : CE, ISO,

Model Number : WJDZ601

MOQ : 1 unit

Price : negotiation

Packaging Details : Carton 109*39*42cm

Delivery Time : 3~7 working days after payment received

Payment Terms : T/T, Western Union

Supply Ability : 5000 units/week

Trade Terms : EXW, FOB, CIF

Type : Folding barrier

Operating time : 3s,6s

Max Boom length : 6m

Boom type : Straight; Folding boom; Fence boom

Housing material : Aluminium alloy

Net Weight : 39kg

Contact Now

Intelligent Barrier Gate With Folding Boom and Anti-bumping Functions

Quick Detail:

(1) Name: Bi-directional Barrier Gate

(2) Application : Parking System

(3) Speed:3/6 second

(4) Feature: Manual release

(5) Rated Power:80W

(6) Certificate:CE, ISO,

(7) Net Weight: 60KG

(8) Voltage: AC220V, AC110V

Description:

Model Selection and Differences

Model	Boom Shape	Max Boom Length	Speed
WJDZ60116	Straight boom	4.5m	6 seconds
WJDZ60113	Straight boom	4m	3 seconds
WJDZ60126	90 degree, Articulated boom	4m	6 seconds
WJDZ60123	90 degree, Articulated boom	3m	3 seconds
WJDZ60136	180 degree, Articulated boom	4m	6 seconds
WJDZ60133	180 degree, Articulated boom	3m	3 seconds
WJDZ60146	Two-level, fence boom	3.5m	6 seconds
WJDZ60156	Three-level, fence boom	3m	6 seconds

Functions & Features:

1. No need to change the balance spring when changing the booms
2. Boom can rise and fall on left/right side by setting on the same machine
3 Advanced manual release
4. Adopts the 3rd generation WEJOIN machine core
5. Supports the infrared photocell for anti-bumping function (optional)
6. Supports the external and internal vehicle loop detector (optional)
7. Auto closing
8. RS485 communication module (optional)
9. Thermal radiates rapidly, no thermal protection
10. Die-cast aluminum alloy machine core and advanced double-stage driving motor effectively solve the problem of mechanism block up
11. Special art and craft makes out the most modernized and fashionable housing
12. Safety photo electricity limit switch

Applications:

Barrier Gate with aluminum alloy housing screen uses the third generation motor. It is stable and has long service life performance, running one million times. And the barrier can work with parking system very well, and can be used in door and outdoor.

Specifications

Model	WJDZ601
Working Temperature	-40℃～+75℃
Voltage	220V±10%, 110V±10%, 50/60HZ
Rated power	120W
Relative humidity	≤90%
Remote control distance	≥30m
Net weight	35kgs
Speed	3S, 6S
Max boom length	6 meters

Intelligent Barrier Gate With Folding Boom and Anti-bumping Functions
